8800DW020 Rosemount Differential Pressure Transmitter

8800DW020 Rosemount Differential Pressure Transmitter
8800DW020 Rosemount Differential Pressure Transmitter 8800DW020 Rosemount Differential Pressure Transmitter 8800DW020 Rosemount Differential Pressure Transmitter 8800DW020 Rosemount Differential Pressure Transmitter

Large Image :  8800DW020 Rosemount Differential Pressure Transmitter

Product Details:
Place of Origin: China
Brand Name: Emerson Rosemount
Certification: ROHS
Model Number: 8800DW020Sk3N2D1I1M5P2Q4
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: negotiable
Packaging Details: standard carton packing
Delivery Time: on request
Payment Terms: T/T
Supply Ability: 1~1000pcs
Detailed Product Description
Flow Meter Accuracy: ± 0.70% Of Mass Flow Rate In Water Using 8800 MultiVariable (MTA Option) ± 2% Of Mass Flow In Steam Using 8800 MultiVariable (MTA Option) ± 1.3% Of Rate At 30 Psia Through 2,000 Psia In Steam Using 8800 MultiVariable (MPA Option) ± 1.2% Of Rate At 150 Psia Wetted Materials: Stainless Steel; 316 / 316L And CF3M Nickel Alloy; C-22 And CW2M High Temp Carbon Steel; A105 And WCB Low Temp Carbon Steel; LF2 And LCC Duplex; UNS S32760 And 6A Consult Factory For Other Wetted Material
MODEL: 8800DW020Sk3N2D1I1M5P2Q4 Origin: China
Process Temperature Limits: -330°F To 800°F (-200°C To 427°C) Temperature Sensor Range: -40 To 800°F (-40 To 427°C)
Flange Options: ANSI Class 150 To 1500 DIN PN 10 To PN 160 JIS 10K To 40K Flanges Are Available In A Variety Of Facings Consult Factory For Additional Flange Ratings
High Light:

8800 Rosemount Differential Pressure Transmitter

,

2 inch Rosemount Differential Pressure Transmitter

,

Rosemount 8800DW020

Emerson Rosemount 8800 MultiVariable Vortex Flow Meter 8800DW020



Description:



Manufacturer : Rosemount

Product No. : 8800DW020Sk3N2D1I1M5P2Q4

Product Type : Vortex Flow Meter

Meter style : F = Flanged

Line Size : 020 = 2 inch (50 mm)

Wetted materials : S = 316 wrought stainless and CF-3M cast stainless; Material of construction is 316/316L.

Process connection style and pressure rating : A1 = ASME B16.5 (ANSI) RF Class 150

Sensor process temperature range : N = Standard: –40 to +450 °F (–40 to +232 °C)

Housing material and conduit entries : 2 = Aluminum housing, two M20 x 1.5 conduit entries

Outputs : F = FOUNDATION Fieldbus digital signal

Calibration : 1 = Flow calibration

Hazardous area approvals : I1 = ATEX Intrinsic Safety ia; Intrinsic Safety ic

Quality certificate

Q4 = Calibration Certification, Certificate of calibration

Q8 = Material Certification, Certificate of material conformance and traceability in accordance with ISO 10474 3.1B and EN 10204 3.1

A01

Weight : 10.5 Kg

Shipping Weight : 15 Kg





Emerson Process Management has recently released a new
revision level of its’ popular Rosemount 8800 Vortex Flowmeter.








Rosemount 8800D Maintained Functionality:


Same non-clog, gasket-free meter body design as the
8800C.
 Available in Flanged, Wafer, Dual, and Reducer™ meter
body designs.
8800D electronics can be used on any 8800 vortex meter.






Rosemount 8800D Enhancements:


Easier configuration by placing all parameters required for
a basic configuration in the same menu.
 Electronics temperature and electronics temperature out
of range diagnostic.
 Simpler Signal Processing Parameter changes in AMS
Device Manager.
Additional Hazardous Area Approvals.







Rosemount 8800D Future Enhancements:


 MultiVariable and temperature compensation functionality
with an integrated temperature sensor.
PlantWeb© Advanced Diagnostics such as Process Alerts
and Sensor Health.
 Help for all parameters integrated into the Device
Descriptor.











Common Models:

8800DF020SK1N2D1E5M5 8800DF020SA3N1P1MTAM5R50Q4
8800DR020SK1N2D1E5M5 8800DF020SA7E1D1E5M5Q4
8800DF020SA1N2D1M5 8800DF060SA3N7D1I1M5Q4Q8T1
8800DF060SA1N1D1M5 8800DF030SA1N1D1MCAM5HR7Q4
8800DF040SA1N2D1M5Q4 8800DF080SA3E1D1MCAM5HR7Q4
8800DF020SA7E1D1M5Q4 8800DD060SA8N2F1E1M5A01Q4Q8
8800DW015SK3N2D1I1M5Q4 8800CW030SA3N1D1E5M5R20Q4
8800DF060SA1N2D1I1Q4M5 8800DW010SA1N2Q1K7M5Q4Q8
8800DW010SK1N1D1I1M5Q4 8800DF005SA1N3F1I1M5A01Q4
8800DF020SA3N2P1E1Q4Q8PD 8800DF010SA1N3F1I1M5A01Q4
8800DF005SA1N2D1I1R10Q4 8800DF015SA1N3F1I1M5A01Q4
8800DF010SA1N2D1I1R10Q4 8800DF020SA1N3F1I1M5A01Q4
8800DW030SA3N1D1E5M5R20Q4 8800DF030SA1N3F1I1M5A01Q4
8800DF060SA1N2D1M5Q4Q8 8800DF040SA1N3F1I1M5A01Q4
8800DW010SA3N2D1M5Q4Q8 8800DF080SA1N3F1I1M5A01Q4
8800DW020SK3N2D1I1M5P2Q4 8800DD060CA8N2F1E1M5A01J7Q4Q8
8800DW010SK3N2D1I1M5P2Q4

8800DF060SA3N7D1I1M5Q4Q8Q5T1





Important terms:

1. Place of delivery (EXW/FOB/CIF): EXW

2. Packing cost: For free

3. Unit weight: Kg/lbs:  8kg

4. Unit dimensions: (W x L x H) : 30*35*30cm

5. HS Code: 90261000

6. Payment terms: TT

7. Warranty: 12 months
