Siemens 7MF8024-1BA14-1AB6 pressure transmitter PN80 made in germany

Siemens 7MF8024-1BA14-1AB6 pressure transmitter PN80 made in germany

The SITRANS P 300 provides measurement accuracy and robustness from the existing SITRANS P DSIII. Its stainless steel casing with laser engraved nameplates and a large number of sanitary process connectors mean it is highly suitable for the food&beverage and pharmaceutical industries.

For the paper industry, SITRANS P300 and DS III pressure transmitters are equipped with special process connections. This process connection is a 1/2 "and 1" PMC threaded connection with a pre membrane, which can be used in all sections of the paper industry. The SITRANS P300 and DS III series pressure transmitters are digital instruments with user-friendly interfaces and high accuracy. Parameterization can be achieved through control keys, HART communication, PROFIBUS PA, or the Foundation's on-site master line interface. The rich functionality makes this pressure transmitter highly suitable for the needs of factories. Despite having a large number of setting options, the operation is still very simple. Transmitters that meet the requirements of "intrinsic safety" and "explosion-proof" explosion-proof types can be installed in potentially explosive atmospheres (Zone 1) or Zone 0. The transmitter has an EC type test certificate and complies with European standards (ATEX). Different models of pressure transmitters can be used to measure: • Gauge pressure • Liquid level • Volume level • Mass level

Siemens 7MF8024-1BA14-1AB6 pressure transmitter

Technical Specifications

precision

≤ 0.075%

long-term stability

≤ 0.25% / 60 months

range

0 - 10 mbar (0 - 4 inchH2O) 0 - 400 bar (0 - 5800 psi)

Features:

·EHEDG (3A) certification for hygiene, materials, and verification is highly suitable for the food, beverage, and pharmaceutical industries

·Specially suitable for process measurement of IP68 and IP69K protection levels, CIP/SIP cleaning, and high viscosity media

·The measuring element is suitable for gauge pressure and pressure measurement

·Measuring element with front diaphragm

·Extended simulation and diagnostic functions, simple parameter settings - communicate via 3 local buttons and LCD display, HART or PROFIBUS PA mode 3.0

Model: 7MF8023 7MF8024 7MF8025
