PMC51-AA21JA1FGBGMJF+AA E+H Absolute and Gauge Pressure Transmitter for -20°C...130°C Process Temperature

PMC51-AA21JA1FGBGMJF+AA E+H Absolute and gauge pressure Cerabar PMC51 -20°C...130°C

Specs at a glance

• Accuracy

  Standard 0.1%
  Platinum 0.075%

• Process temperature

  -20°C...130°C
  (-4°F...266°F)

• Pressure measuring range

  100 mbar...40 bar
  (1.5psi...600psi)

• Process pressure / max. overpressure limit

  60 bar (900 psi)

• Main wetted parts

  Ceraphire
  Sealing
  Alloy C276
  316L

• Max. measurement distance

  400 m (1312 ft) H2O

• Material process membrane

  Ceramic

• Measuring cell

  100 mbar...40 bar
  (1.5 psi...600 psi)
  relative/ absolute



  Field of application

  The Cerabar PMC51 digital pressure transmitter with capacitive, oil-free ceramic measuring cell is typically used in process and hygienic applications for pressure, level, volume or mass measurement in liquids and gases. It guarantees high degree of system safety thanks to vacuum-proof ceramic membrane with integrated breakage detection. Quick Setup with adjustable measuring range allows simple commissioning, reduces costs and saves time. SIL2 according to IEC 61508 / IEC 61511.

  Benefits



  Best fit for vacuum applications and applications with corrosive and abrasive media

  Process safety through membrane breakage detection

  Overload-resistant high purity ceramic sensor (99.9% Al2O3)

  Condensation resistant also for hygienic applications

  Easy menu-guided commissioning via local display, 4 to 20mA with HART, PROFIBUS PA, FOUNDATION Fieldbus

  Process pressure up to SIL2, certified to IEC 61508 and IEC 61511

  Available with mounted manifolds: always fit, always tested for leaks
