Endress+ Hauser CCS51D-AA11BF Digital free chlorine sensor Memosens

Endress+ Hauser CCS51D-AA11BF Digital free chlorine sensor Memosens

Description:

Manufacturer : Endress+Hauser

Product No. : CM444-2PL8/0

Product type : 4-channel Transmitter Liquiline

Universal four-wire multichannel controller Field device

Shipping weight : 10 Kg

Additional Informaiton:

Memosens sensor for drinking water, pool and process water as well as utilities in all industries
Memosens CCS51D is a robust, low-maintenance sensor for free chlorine. It provides high-precision measurement with long-term stability in drinking water, pool and process water and ensures consistent disinfection monitoring even at low water volumes. The free chlorine sensor features extremely fast response times guaranteeing efficient process control and safe processes. Thanks to Memosens digital technology, CCS51D combines maximum process and data integrity with simple operation.

Benefits

The right sensor version for every application: From trace measurement up to free chlorine concentrations of 200 mg/l.

Fast response time (t90 < 25 s) provides an accurate process view and enables prompt reaction to process changes as well as efficient process control.

Increased process safety: precise and long-term stable measurement ensures consistent process monitoring and allows for individually adapted disinfectant dosing.

The low-maintenance, amperometric sensor reduces the cost of ownership of the measuring point, particularly compared to colorimetric measuring systems.

More process up-time thanks to fast sensor exchange: pre-calibrate the sensor in your lab and then swap it into your process with plug & play.

Connection to the Liquiline multiparameter transmitter allows for easy combination with other relevant parameters of liquid analysis such as pH and ORP.

Show less

Field of application

Memosens CCS51D is a free chlorine sensor for skid builders and end customers. It measures reliably in:

Drinking water - to ensure reliable disinfection

Food - to guarantee food safety and provide hygienic packaging and bottling

Utilities - to detect the absence or presence of free chlorine

Pool water - to dose disinfectant efficiently

Show less
Features and specifications
Disinfection
Measuring principle
Free chlorine

Application

Ensuring reliable disinfection in drinking water
Process water
Dosing disinfectant efficiently in pool water
Detect the absence or presence of free chlorine in Utilities
Guarantee food safety and provide hygienic packaging and bottling

Characteristic
Amperometric measurement of dissolved free chlorine

Measurement range

Trace: 0 to 5 mg/l HOCl

Standard: 0 to 20 mg/l HOCl
High: 0 to 200 mg/l HOCl

Measuring method
Closed, membrane covered measuring cell
Reduction of free chlorine at the cathode

Design
Closed amperometric 2-electrode measuring cell with PVDF membrane

Material
Sensor shaft: PVC

Membrane: PVDF

Membrane cap: PVDF

Sealing ring: FKM

Dimension
Diameter: 25 mm (0.98 inch)

Length: 161 mm (6.34 inch)

Process temperature

0 to 55 °C (32 to 130 °F), non-freezing

Process pressure
Max. 1 bar (max. 14.5 psi)

Temperature sensor
10k NTC integrated (Memosens)

Connection
Inductive, digital connection head with Memosens
