VEGASON 61 VEGA61 Ultrasonic Level Gauge Imported From VEGA _SN61. XXAGHDMXX

MOQ: 1
Price: Negotiable
Standard Packaging: CARTON
Delivery Period: Negotiable
Payment Method: T/T
Supply Capacity: 500+pcs+on stock
Details Information
Product Description
Detail Information
Place of Origin
GERMANY
Brand Name
VEGA
Certification
rohs
Model Number
SN61. XXAGHDMXX
Measuring Range - Pressure:
-10 ... 1000 Bar
Origin:
Germany
Lead Time:
8week
Warranty:
1year
Goods:
Brand New And Original
Color:
Yellow And Black
Highlight:

VEGA61 ultrasonic level gauge

,

VEGASON 61 ultrasonic level gauge

,

Ultrasonic Level Gauge

Product Description

VEGASON 61 VEGA61 ultrasonic level gauge imported from VEGA _SN61. XXAGHDMXX

VEGASON 61 VEGA61 Ultrasonic Level Gauge Imported From VEGA _SN61. XXAGHDMXX 0VEGASON 61 VEGA61 Ultrasonic Level Gauge Imported From VEGA _SN61. XXAGHDMXX 1



■ Advantages

- Maintenance-free, the equipment is widely applicable.

- Accurate and reliable measurements.

- Simple to use and economical to use.

■ Applications

The VEGASON 61 is used for continuous level measurement of liquid and solid bulk materials. It is suitable for storage tanks and open storage pools for liquids, as well as for small storage tanks and open containers for solid bulk materials. VEGASON61 is economical, simple and flexible to install, and can be set up without media.



Scope of application: liquid, solid bulk materials
Measuring distance Liquid: 0.25~5 meters, Solid bulk material: 0.25~2 meters
Measurement accuracy ± 10 mm
The working environment temperature is -40~ 80°C
Operating Ambient Pressure -0.2~ 2bar (-20~ 200 kPa)



XX

No explosion-proof requirements

XM
Marine License

CX

ATEX II 1G, 1/2G, 2G Ex ia IIC T6

CM
ATEX II 1G, 1/2G, 2G Ex ia IIC T6 Marine Approval
CI
IEC Ex ia IIC T6

│
Version/Operating Temperature:

│
A

EPDM package/-40~80°C

│
B
FKM (Viton) package/-20~80°C

│
│
Mounting Connections/Materials:

│
│
G

Thread G1 1/2 (DIN3852-A-B) / PVDF

│
│
N

Thread 1 1/2" NPT (ASME B1.20.1) / PVDF

│
│
│
Output Interface:

│
│
│
H
Two-wire system 4~20mA/HART

│
│
│
V
Four-wire system 4~20mA/HART

│
│
│
P
Profibus PA

│
│
│
F
Foundation Fieldbus

│
│
│
│
Enclosure/Degree of Protection:

│
│
│
│
K
Plastic enclosure / IP66/IP67

│
│
│
│
A
Aluminium housing / IP66/IP68 (0.2 bar)

│
│
│
│
D
Aluminium double chamber / IP66/IP68 (0.2 bar)

│
│
│
│
8
Stainless steel (electropolished) 316L / IP66/IP68 (0.2 bar)

│
│
│
│
W
Stainless steel double chamber / IP66/IP68 (0.2 bar)

│
│
│
│
R
Plastic double chamber / IP66/IP67

│
│
│
│
│
Cable Interfaces/Connectors:
M
M20x1.5 / None

N
┄
┄
┄
1/2NPT/None

│
│
│
│
│
│
Display Debugging Module (PLICSCOM):

│
│
│
│
│
│
X
┄
┄
not

│
│
│
│
│
│
A
┄
┄
Top mounted

│

Tags:

75m VEGA Level Meter,

61 VEGA Level Meter,

VEGA Vibration Type Level Switch
