VEGA CAP62 Level Meter Capacitive Rod Probe High Precision Measurement for Extreme Temperature Pressure Environments

The VEGA CAP62 Level Meter (Model CAP62.XXAGCRKM) is a German-engineered capacitive rod probe designed for high-precision point level detection in the most demanding industrial environments. Engineered by VEGA Grieshaber KG, a globally recognized leader in level and pressure measurement technology, this instrument delivers unmatched reliability across an extraordinary operating envelope from cryogenic conditions at -50°C to extreme heat at 200°C, while withstanding process pressures from vacuum up to 64 Bar. The CAP62 combines advanced capacitive sensing technology with robust mechanical construction, making it the preferred choice for petrochemical refineries, power generation plants, offshore platforms, and high-temperature chemical processing facilities where measurement failure is not an option. With a sensor length of up to 6 meters, flexible installation options, and a comprehensive range of output protocols, the CAP62 seamlessly integrates into both legacy and modern control systems while maintaining exceptional signal stability and measurement repeatability even under fluctuating process conditions.

• Extreme Temperature Range: Operates reliably from -50°C to 200°C, covering applications from LNG cryogenic storage to superheated steam vessels and high-temperature reactor monitoring.
• High-Pressure Endurance: Withstands process pressures from -1 Bar (vacuum) to 64 Bar, making it suitable for high-pressure reactor vessels, steam boilers, autoclaves, and deep-well level measurement applications.
• Superior Measurement Precision: Advanced capacitive sensing technology with built-in signal conditioning ensures consistent, repeatable switching accuracy regardless of medium conductivity, density variations, or buildup on the probe surface.
• Non-Contact Seal Design: The innovative no-media-contact seal material eliminates the risk of seal degradation, chemical attack, and cross-contamination, significantly extending operational service life in aggressive chemical and high-purity applications.
• Versatile Installation Options: Compatible with threaded connections from G½ and ½ NPT as well as flange connections from DN25 and 1 inch, enabling seamless integration into existing piping and vessel configurations without costly modifications.
• Rugged Industrial Construction: Available with housing options in plastic, aluminium, stainless steel precision casting, or electropolished stainless steel, paired with IP66/IP67 or IP66/IP68 protection ratings for reliable outdoor and washdown duty.
• Multi-Protocol Output Flexibility: Supports relay (DPDT), contactless electronic switch, transistor (NPN/PNP), and two-wire output configurations, ensuring compatibility with diverse PLC, DCS, and SCADA control architectures.

The VEGA CAP62 Level Meter excels across a broad spectrum of challenging industrial applications where precision, durability, and operational safety are paramount. In petrochemical refineries and downstream processing plants, it provides reliable level detection in distillation columns, separator vessels, and storage tanks handling hydrocarbons at elevated temperatures and pressures. Power generation facilities deploy the CAP62 for boiler drum level monitoring, feedwater heater level control, and condensate tank management. Offshore oil and gas platforms rely on its corrosion-resistant construction for produced water tanks, chemical injection skids, and flare knockout drums exposed to harsh marine environments. High-temperature chemical and pharmaceutical manufacturing operations trust the CAP62 for reactor level monitoring, solvent recovery systems, and sterile processing vessels where material compatibility and CIP/SIP resilience are critical. The instrument also serves marine ballast water treatment systems, LNG/LPG cryogenic storage terminals, and bulk solids silos handling powders, granules, and fine-grained materials with densities as low as 0.02 g/cm³. Its adjustment-free setup and robust mechanical design make it equally effective as overfill protection, dry run prevention, and leak detection across the entire process industry spectrum.

Every VEGA CAP62 Level Meter is shipped in original manufacturer packaging with multi-layer shock-proof foam inserts and an export-grade corrugated carton to ensure safe international transit. Great System Industry (GSI) performs incoming quality inspection on all units prior to dispatch, including visual inspection, dielectric integrity verification, and functional switching point confirmation. Each shipment includes the manufacturer certificate of conformity, calibration documentation, and a comprehensive installation and operating manual. GSI maintains 500+ units of VEGA instrumentation in inventory, enabling rapid fulfillment for urgent project timelines. Standard delivery is 5 to 15 working days via DHL, UPS, FedEx, or TNT, with express options available on request. All products are covered by the full manufacturer warranty with GSI providing ongoing technical support, commissioning assistance, and after-sales service throughout the product lifecycle.
